Description 7D0 698 151 F Brake Pad Set SET Front Axle
Brake System : ATE
Width : 156.3 mm
Height : 68.6 mm
Thickness : 19.8 mm
| Model | Engine | Chassis | Type | CYL | year | ||
|---|---|---|---|---|---|---|---|
| VOLKSWAGEN TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) | 9/95 - 4/03 | ||||||
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 1.9 D | 1X | 1896 | 61 | Box | 4 | 7/90 - 2/95 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 1.9 TD | ABL | 1896 | 68 | Box | 4 | 0/92 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.0 | AAC | 1968 | 84 | Box | 4 | 7/90 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.4 D | AAB | 2370 | 78 | Box | 5 | 7/90 - 4/98 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.4 D | AJA | 2370 | 75 | Box | 5 | 8/97 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.4 D Syncro | AAB | 2370 | 78 | Box | 5 | 0/92 - 9/98 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 | AAF | 2461 | 110 | Box | 5 | 1/90 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 | AET | 2461 | 115 | Box | 5 | 8/96 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 Syncro | AAF | 2461 | 110 | Box | 5 | 0/92 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 Syncro | AET | 2461 | 115 | Box | 5 | 8/96 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 TDI | ACV | 2461 | 102 | Box | 5 | 9/95 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 TDI | AJT | 2461 | 88 | Box | 5 | 2/98 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 TDI | AXG | 2461 | 151 | Box | 5 | 9/00 - 4/03 | |
| TRANSPORTER IV Box (70A, 70H, 7DA, 7DH) 2.5 TDI Syncro | ACV | 2461 | 102 | Box | 5 | 9/95 - 4/03 | |
| VOLKSWAGEN TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) | 1/95 - 4/00 | ||||||
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 1.9 D | 1X | 1896 | 60 | Bus | 4 | 9/90 - 2/95 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 1.9 TD | ABL | 1896 | 68 | Bus | 4 | 0/92 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.0 | AAC | 1968 | 84 | Bus | 4 | 9/90 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.4 D | AAB | 2370 | 78 | Bus | 5 | 9/90 - 4/98 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.4 D | AJA | 2370 | 75 | Bus | 5 | 8/97 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.4 D Syncro | AAB | 2370 | 78 | Bus | 5 | 0/92 - 9/98 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 | AAF | 2461 | 110 | Bus | 5 | 1/90 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 | AET | 2461 | 115 | Bus | 5 | 8/96 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 Syncro | AAF | 2461 | 110 | Bus | 5 | 1/92 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 Syncro | AET | 2461 | 115 | Bus | 5 | 7/96 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 TDI | ACV | 2461 | 102 | Bus | 5 | 9/95 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 TDI | AJT | 2461 | 88 | Bus | 5 | 5/98 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 TDI | AHY | 2461 | 151 | Bus | 5 | 5/98 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.5 TDI Syncro | ACV | 2461 | 102 | Bus | 5 | 1/96 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.8 VR6 | AMV | 2792 | 204 | Bus | 6 | 4/00 - 4/03 | |
| TRANSPORTER IV Bus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ) 2.8 VR 6 | AES | 2792 | 140 | Bus | 6 | 1/95 - 4/00 | |
| VOLKSWAGEN TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D | 8/96 - 4/03 | ||||||
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 1.9 D | 1X | 1896 | 61 | Platform/Chassis | 4 | 7/90 - 2/95 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 1.9 TD | ABL | 1896 | 68 | Platform/Chassis | 4 | 0/92 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 TDI | ACV | 2461 | 102 | Platform/Chassis | 5 | 9/95 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 TDI | AJT | 2461 | 88 | Platform/Chassis | 5 | 5/98 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 TDI Syncro | ACV | 2461 | 102 | Platform/Chassis | 5 | 5/98 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.0 | AAC | 1968 | 84 | Platform/Chassis | 4 | 7/90 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.4 D | AAB | 2370 | 78 | Platform/Chassis | 5 | 9/90 - 4/98 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.4 D | AJA | 2370 | 75 | Platform/Chassis | 5 | 8/97 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.4 D Syncro | AAB | 2370 | 78 | Platform/Chassis | 5 | 0/92 - 9/98 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 | AAF | 2461 | 110 | Platform/Chassis | 5 | 1/90 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 | AET | 2461 | 115 | Platform/Chassis | 5 | 8/96 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 Syncro | AAF | 2461 | 110 | Platform/Chassis | 5 | 0/92 - 4/03 | |
| TRANSPORTER IV Platform/Chassis (70E, 70L, 70M, 7DE, 7DL, 7D 2.5 Syncro | AET | 2461 | 115 | Platform/Chassis | 5 | 8/96 - 4/03 | |
Application
VOLKSWAGEN EuroVan 2000
- Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system - Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
- Rear brakes is recommended to replace within 5-7 km
- Replace the Disc brake when follow situation happen:
- 1.Sensor alarm;
- 2.Friction materials thickness less than 3mm;
- 3.Friction materials becomes contaminated with brake fluid;
- 4.Uneven wear within a set;
- Replace the brake rote when follow situation happen:
- 1.Vibrate when braking;
- 2.Car vehicle performance more than 60000Km and braking unstable;
- 3.Disc brake thickness wear more than 2mm;
